5.8m portable toilet trailer — dual axle, 2 rooms (3 toilets + 2 toilets), white exterior, 110V/60Hz power, fresh & waste tanks, ducted 110V HVAC, complete internal fixtures and service ports.
Purpose-built for rental companies and event operators who need a compact unit with high passenger throughput.
Fully equipped — arrives ready to connect: electrical, water inlet/outlet, pumps and meters pre-installed.
Comfortable: each room gets conditioned air via ducted HVAC and room vents; under-sink instant water heaters (small “point-of-use” units) provide warm handwashing.
Road-ready: dual axle, mechanical brakes, aluminum alloy hubs, RV jacks and steps for safe towing and stable onsite setup.
Service-friendly: equipment room holds pump, control box and HVAC system for straightforward maintenance.
Dimensions: 5.8 m × 2.1 m × 2.55 m (L × W × H).
Layout: 2 rooms — Room A: 3 toilets; Room B: 2 toilets.
Exterior color: White.
Chassis & wheels: Dual axle, 4 wheels; aluminum alloy wheel hubs; mechanical braking system; RV-style jacks and step.
Power: 110 V / 60 Hz, US standard sockets; shore power compatible (US plug).
Water tanks: fresh water tank (plastic) + sewage/waste tank — sized per customer needs (factory standard installed).
Fixtures & fittings included: toilets, washbasins, mirrors, toilet paper dispensers, soap dispensers, occupancy indicators, door handles, clothing hooks.
Under-sink heaters: small point-of-use water heaters installed beneath each sink for immediate warm water.
Ventilation: internal exhaust fans in each room for odor control.
Equipment room: water pump (RV-type), water meter/sewage meter, electrical control box, HVAC unit (110V), ducting to feed each room, and service access.
HVAC: one 110V ducted cold/warm air conditioner placed inside the equipment room with ducts and supply outlets to all stalls. Uses stocked (in-house) AC unit.
Electrical & plumbing ports: external water inlet, sewage outlet, brake wiring/connector, sewage meter access, marker/clearance lights, and shore-power socket.
Audio & safety: integrated music/system speaker, marker lights, brake lights and clearance lamps included.
Shipping / handling: configured for standard export; local reassembly may be required depending on destination rules.
| Item | Specification |
|---|---|
| Model / Type | 5.8m Portable Toilet Trailer (2-room: 3+2 toilets) |
| Exterior size | 5.8 × 2.1 × 2.55 m |
| Axles / Wheels | Dual axle, 4 wheels; aluminum alloy hubs |
| Brakes | Mechanical brakes; brake wiring & lights included |
| Rooms / Fixtures | Room A: 3 toilets; Room B: 2 toilets; sinks, mirrors, paper & soap dispensers |
| Water tanks | Fresh water (plastic) + sewage tank (factory-installed) |
| Under-sink heaters | Point-of-use small water heaters under every sink |
| Ventilation | Exhaust fans in each room |
| HVAC | 1 × 110V ducted cold/warm unit in equipment room; ducts to each room |
| Power | 110V / 60Hz, US standard sockets (shore power compatible) |
| Equipment room | Pump, water meter, sewage meter, electrical control box, AC + ducting |
| Exterior color | White |
| Extras | Inlet/outlet ports, marker lights, music system, door handles, hooks |
Festival & concert rentals
Wedding & private events
Film production sites & outdoor sets
Construction & mining camps
Emergency response & temporary medical facilities
Municipal or park installations for temporary periods
Connect shore power (110V/60Hz) and top up fresh water at the external inlet.
Sewage emptied via the external sewage outlet; use the sewage meter to monitor tank levels.
Ensure shore power cable is rated for outdoor use and connected to a GFCI-protected source per local code.
Routine maintenance: inspect seals, test under-sink heaters and pump operation, clean exhaust filters and test HVAC airflow.
For export/shipping, ask about wheel/axle removal procedures if required by destination.
Add a partition to convert one room into an accessible stall (ADA-compliant design available on request).
Increase fresh/sewage tank capacities for longer deployments.
Add solar pre-charge for battery-backed lighting/audio systems.
Branding: custom exterior wrap or full vehicle paint matching corporate color.
Upgrade fixtures to stainless steel or anti-vandal hardware for heavy-use rental fleets.
